5 MWh Liquid-cooled Containerized Energy Storage System(1P104S)

Security
Reliability
Multiple Scenarios
Intelligent Platform
  • Real-time fire detection, pack-level precision protection.
  • Supports large-scale application scenarios across the user, generation, and grid sides.
  • Supports usage via mobile apps and the web, featuring cloud storage and data analytics.
  • Real-time fire detection, pack-level precision protection.
  • Supports large-scale application scenarios across the user, generation, and grid sides.
  • Supports usage via mobile apps and the web, featuring cloud storage and data analytics.
  • Real-time fire detection, pack-level precision protection.
  • Supports large-scale application scenarios across the user, generation, and grid sides.
  • Supports usage via mobile apps and the web, featuring cloud storage and data analytics.
  • Real-time fire detection, pack-level precision protection.
  • Supports large-scale application scenarios across the user, generation, and grid sides.
  • Supports usage via mobile apps and the web, featuring cloud storage and data analytics.
Download

PRODUCT SPECIFICATIONS

Battery Pack Parameters

Item Parameters
Cell Type LFP 314Ah
Configuration 1P104S
Nominal Voltage (Vdc) 332.8
Nominal Energy (kWh) 104.5
Power Rate (Cp) ≤0.5

Battery Rack Parameters

Item Parameters
Pack Series 4S
Working Voltage (Vdc) 1164.8~1497.6
Nominal Voltage (Vdc) 1331.2
Nominal Energy (kWh) 417.9968
Power Rate (Cp) ≤0.5

ESS System Parameters

Item Parameters
Rack Qty. 12
Nominal Voltage (Vdc) 1331.2
Nominal Energy (kWh) 5016
Power Rate (Cp) ≤0.5
Wiring Method DC convergence

General Parameters

Item Parameters
Dimension（W*D*H,mm） 6058*2550*3100
Weight (t) ＜54.5
Working Temperature (℃) -30~55
Relative Humidity (%RH) 0~95%RH
Altitude (m) ≤3000
Cooling Method Liquid Cooling
IP Rating IP54
Communication Wireless 4G/Ethernet
Wiring Method Bottom in and bottom out
Fire Protection Pack-grade perfluorohexanone, with provision for water-based fire suppression system.

ENERGY STORAGE SYSTEM

Containerized Liquid-Cooled Energy Storage System For All Scenarios

Liquid Cooling

The liquid cooling system keeps temperature difference within the rack ≤3°C, reduces thermal management power consumption by 40%, and saves space while improving battery life.

Highly efficient heat dissipation minimizes battery temperature differences

Pack-Level Fire Control System

Each cell has an individual fire detection tube, enabling early detection, fire distinguishing, and water-based firefighting – an optimized strategy for maximum safety.

Precision fire protection at the cell level

Non Walk-In Structure

The container is designed without walk-in access, which boosts system integration efficiency and reduces risks during operation and servicing.

Safer, simpler installation and maintenance

DC 1500V High-Voltage System

This system improves ESS energy density by over 30%, cuts integration and maintenance costs by 10%, and minimizes parallel-connection losses for higher operational efficiency.

Higher energy density, lower cost and loss
